TEAC

TEAC AD-850

Cassette Deck and CD Player, Silver (USED)

TEAC AD-850

$495.00
$495.00
SALE Sold Out
Free shipping
Product questions? Found a lower price?
Let us know: 443-402-5055 or text us 443-402-5064.
Have a trade-in item? Click here.

Trade-in Form

Tell us about yourself

Tell us about your trade-in item(s)

Trade-in item 1
Any technical problems with this piece?
Any scratches, dents, discoloration, or other physical wear?
Do you have the original accessories (manual, remote, power cable, etc.)?
Do you have the original product packaging?

The TEAC AD-850 puts a CD player and a cassette deck in one full width chassis, with USB recording and playback alongside them. The CD section handles CD, CD-R and CD-RW discs including MP3 discs, and the cassette section records and plays normal and chrome tapes. Because both transports and the USB port share the same box, it will dub a CD straight to tape or to a USB drive, and copy a tape across to USB, with nothing else in the chain.

A microphone input sits on the front for recording and sing-along use, pitch control trims playback speed on the cassette side by up to 10 percent, and a stereo RCA line output feeds any amplifier or receiver. This is the silver finish.

Specs
Type Cassette deck and CD player combination with USB recording and playback
CD Pickup 3 beam semiconductor laser
CD Digital Filter 8 times oversampling
CD Media Supported CD, CD-R, CD-RW, including MP3 discs
CD Frequency Response 20 Hz to 20 kHz, +/-2 dB
CD Total Harmonic Distortion 0.02% or less (1 kHz)
CD Signal to Noise Ratio 87 dB or more (IHF-A)
CD Analog Output 2.0 V (RCA)
Cassette Track System 4 track, 2 channel stereo
Cassette Heads Record and playback x 1, erase x 1
Cassette Tape Types Normal and chrome (C-46/60)
Cassette Tape Speed 4.76 cm/sec
Cassette Motor DC servo motor x 1
Pitch Control +/-10% (playback only)
Cassette Wow and Flutter 0.25% (W. RMS)
Cassette Frequency Response 50 to 12,000 Hz +/-3 dB (chrome and normal)
Cassette Signal to Noise Ratio 59 dB (3% THD level, weighted)
Rewinding Time Approx. 120 sec with a C-60
USB Interface USB 1.1 Full Speed
USB Playback 20 Hz to 20,000 Hz (+/-2 dB), 85 dB or more, 8 to 320 kbps
USB Recording CD to USB 20 Hz to 15 kHz (+/-3 dB), line to USB 100 Hz to 15 kHz (+/-3 dB), 128 kbps
Line Input (RCA) 462 mV, input impedance 50 kohms or more
Line Output (RCA) 462 mV, load impedance 50 kohms or more
Microphone Input 6.3 mm mono standard jack, 0.78 mV nominal, 47 kohms or more
Power Requirement AC 120 V, 60 Hz (USA and Canada model)
Power Consumption 14 W
Dimensions (W x H x D) 435 x 145 x 288 mm (17 1/4 x 5 3/4 x 11 3/8 in), including protrusions
Weight 4.8 kg (10 5/8 lb)
Finish Silver

See pictures for condition. Comes with all original accessories. If you have any questions about the condition or what accessories are included, please give us a call.
