Velodyne Acoustics MiniVee X Subwoofer

Velodyne Acoustics MiniVee X – Ultra‑Compact High‑Performance Subwoofer

The MiniVee X is Velodyne’s compact yet capable subwoofer, designed to deliver deep, precise bass from a small footprint. By combining a long‑throw 8″ active driver with a matching passive radiator, it achieves strong output and minimal cabinet vibration—perfect for listeners who want impactful bass without bulky gear.

Key Specifications & Features

• Amplifier & Power
  • Class D amplifier rated at 350 W RMS (0.5% THD), 600 W (2% THD), and 800 W peak capability.
  • Oversized ferrite magnets and robust MOSFET power stage support dynamic headroom and clarity.


• Driver & Acoustic Design
  • Proprietary 8″ long‑throw driver with tuned overhung motor design ensures accurate motion and control.
  • 8″ passive radiator working in tandem to reduce movement stress on the cabinet, increasing musical precision.


• Frequency Response
  • ±3 dB: 32 – 180 Hz
  • Extended range (overall): 18 – 300 Hz


• Crossover & Phase Control
  • Low-pass crossover adjustable from 30 Hz to 200 Hz (12 dB/octave).
  • Phase control from 0° to 180° to align subwoofer output with main speakers.


• Cabinet & Build
  • Sealed (closed-box) MDF construction with internal bracing to minimize resonance.
  • Finish: high-gloss black (other finishes available in select markets).
  • Dimensions (W × H × D, with feet and connectors): 29 × 30 × 29 cm
  • Weight: ~15 kg


• Connectivity & Controls
  • Inputs: Stereo RCA / LFE RCA (gold-plated), Balanced XLR, high-level (speaker-level) inputs, 12 V trigger input.
  • Outputs: Pass-through Stereo / LFE RCA and Balanced XLR.
  • Additional: USB port (5 V / 1 A) for optional Wi‑Connect II wireless module, front mic input for calibration.
  • Power modes: Off / Auto / On, with LED indicators for standby and active mode.


• App-Based Auto EQ & Tuning
  • Free Velodyne Auto EQ mobile app (iOS / Android) allows room measurement and calibration using the included microphone.
  • Customizable parametric EQ, multiple presets, crossover, and phase control remotely.
