Silent Angel Bonn N16 LPS Audiophile Network Switch with Linear Power Supply

Reference grade network switch featuring sixteen Gigabit Ethernet ports, dual isolated network zones, precision TCXO clocking, and an integrated linear power supply for high performance music streaming systems.

Built Specifically for High Resolution Audio Networks

The Silent Angel Bonn N16 LPS was designed for audiophiles who have moved beyond the limitations of conventional networking hardware. While ordinary network switches are engineered for office environments where speed and data throughput are the primary concerns, the Bonn N16 LPS was developed specifically for digital audio systems where signal integrity, timing accuracy, and noise reduction become increasingly important.

As streaming continues to replace physical media as the primary source for music playback, the quality of the network infrastructure feeding a streamer, server, or DAC becomes a more significant part of overall system performance. The Bonn N16 LPS serves as a dedicated audio network hub designed to create a cleaner, more stable environment for digital music transmission.

Dual Zone Architecture for Superior Isolation

The defining feature of the Bonn N16 LPS is its unique dual zone design. Rather than operating as a single sixteen port switch, the unit incorporates two completely independent eight port Gigabit Ethernet subsystems housed within one chassis. Each zone operates independently with its own dedicated clock circuitry and power regulation.

This architecture allows users to separate audio devices from general household network traffic. One zone can be dedicated to streamers, music servers, NAS drives, and DACs while the second zone handles computers, televisions, gaming systems, and other network devices. By physically separating traffic flows, the Bonn N16 LPS reduces interference and minimizes the impact of network congestion on audio playback.

The dual zone design also supports daisy chain configurations where one zone feeds the second zone, creating an additional layer of network purification before audio devices receive the signal. This flexibility allows the Bonn N16 LPS to adapt to a wide variety of system requirements.

Integrated Linear Power Supply

Unlike most network switches that rely on inexpensive switching power supplies, the Bonn N16 LPS incorporates a sophisticated internal linear power supply. Silent Angel developed this architecture using technology derived from the company's Forester power supply designs.

The power supply utilizes a toroidal transformer along with advanced regulation circuits and fast response MOSFET devices. By providing cleaner and more stable power to the network circuitry, the Bonn N16 LPS minimizes electrical noise that could otherwise contaminate sensitive digital audio systems. The integrated design eliminates the need for an external power supply while maintaining the performance expected from a premium audio component.

Precision Clocking for Accurate Data Transmission

Each network zone incorporates its own dedicated TCXO clock module powered through isolated linear regulation circuits. TCXO technology provides significantly greater timing precision than the crystal oscillators commonly found in conventional networking equipment.

Silent Angel specifies these clock modules as approximately fifty times more precise than standard crystal clock designs. Improved timing precision helps reduce jitter and contributes to more accurate packet transmission across the network. For demanding digital audio applications, maintaining timing accuracy throughout the signal chain is an important part of achieving optimal playback performance.

External Clock Upgrade Capability

The Bonn N16 LPS is designed to grow alongside an evolving system. Owners seeking even greater timing precision can connect an external 25MHz master clock such as the Silent Angel Genesis GC.

External clock synchronization allows the network switch to operate from a dedicated high precision timing reference rather than relying solely on its internal clock circuitry. This capability places the Bonn N16 LPS among the more advanced network switch solutions available to serious streaming enthusiasts.

Designed for Roon and Streaming Ecosystems

The Bonn N16 LPS was optimized specifically for modern streaming platforms and network audio environments. It integrates seamlessly with Roon based systems, music servers, network attached storage devices, and high resolution streaming services such as Qobuz, TIDAL, and Spotify.

Within the Silent Angel ecosystem, the Bonn N16 LPS works exceptionally well alongside products such as the Rhein Z1 music servers and Munich series streamers. The result is a highly organized digital infrastructure capable of supporting even the most demanding streaming systems.

Rack Ready Construction

Unlike many compact audiophile switches, the Bonn N16 LPS is designed for rack installation. The chassis occupies a standard single rack unit height and includes mounting hardware for integration into equipment racks and custom installations.

This makes the Bonn N16 LPS particularly attractive for dedicated listening rooms, whole home audio systems, and larger installations where clean cable management and centralized equipment organization are priorities. Despite its professional form factor, the design remains equally comfortable on a traditional audio rack or equipment shelf.

How the Bonn N16 LPS Compares to the Bonn N8

The Bonn N8 remains an excellent entry point into audio grade networking and provides eight Gigabit ports within a compact chassis. The Bonn N16 LPS expands substantially upon that foundation by incorporating two isolated network zones, sixteen total ports, dedicated clock modules for each zone, rack mount capability, and a fully integrated linear power supply.

For larger streaming systems with multiple networked components, the Bonn N16 LPS offers significantly greater flexibility and system organization while delivering a higher level of network isolation and power supply sophistication.

The Foundation of a Reference Streaming Network

As digital audio systems become more complex, the importance of network infrastructure continues to grow. The Bonn N16 LPS provides a dedicated platform designed specifically to support high performance streaming environments. Through its dual zone architecture, precision clocking, integrated linear power supply, and upgrade flexibility, it serves as a powerful foundation for serious digital music systems.

Key Specifications Block

• Product: Silent Angel Bonn N16 LPS
• Category: Audiophile Network Switch with Linear Power Supply
• Price: $1,999
• Ethernet Ports: 16 Gigabit Ethernet RJ45
• Network Architecture:
  • Two Independent 8 Port Zones
• Clock Technology:
  • Dual TCXO Clock Modules
• Clock Accuracy:
  • 0.1 ppm
• External Clock Support:
  • 25MHz Master Clock Input
• Power Supply:
  • Integrated Linear Power Supply
• Transformer:
  • Toroidal Transformer
• Power Consumption:
  • 50W Maximum
• Network Speed:
  • 1000Mbps Gigabit Ethernet
• EMI Protection:
  • High Permeability EMI Absorbers
• Installation:
  • Rack Mount Ready
  • Rack Hardware Included
• Operating Temperature:
  • 32°F to 86°F
• Width:
  • 17.37 Inches
  • 441.2 mm
• Height:
  • 1.74 Inches
  • 44.2 mm
• Depth:
  • 6.54 Inches
  • 166.1 mm
• Weight:
  • 6.62 Pounds
  • 3 kg
• Finish:
  • Black
• Included Accessories:
  • Power Cable
  • Ethernet Cable
  • Rack Mount Kit
  • Rubber Feet
• Warranty:
  • 2 Year Manufacturer Warranty
• Country Voltage:
  • 100V to 240V AC
  • 50Hz to 60Hz

Why Buy From All Elite Audio

All Elite Audio is an authorized dealer for Silent Angel and every brand we carry. Every product we sell is sourced directly through authorized distribution channels and includes full manufacturer support.

Call: 443-402-5055

Text: 443-402-5064

Visit: 1921 York Rd, Timonium, MD 21093

FAQ

What does the Bonn N16 LPS actually do?

The Bonn N16 LPS is a specialized network switch designed for high performance audio streaming systems. Its purpose is to manage and distribute network traffic while reducing electrical noise, interference, and timing inconsistencies that can affect digital audio components. Unlike a standard computer network switch, it incorporates dedicated audio focused technologies including TCXO clocking, dual network zones, and an integrated linear power supply. These design elements help create a cleaner network environment for music playback.

Why does a network switch matter for audio streaming?

Every music stream passes through networking equipment before reaching your streamer, server, or DAC. Standard networking hardware is designed primarily for data transfer efficiency and cost reduction. The Bonn N16 LPS focuses on minimizing electrical noise, reducing jitter, and maintaining timing precision throughout the network path. In highly resolving systems, these improvements can contribute to a more refined streaming experience.

What are the benefits of the dual zone design?

The dual zone architecture allows users to separate audio devices from other network traffic. One zone can support streamers, music servers, and NAS devices while the second zone handles household devices such as computers and televisions. Physical separation reduces interference between traffic types and creates a cleaner environment for audio playback. The architecture also supports daisy chain configurations for additional network isolation.

Does the Bonn N16 LPS include a linear power supply?

Yes. One of the major advantages of the Bonn N16 LPS is its integrated linear power supply. Rather than using a conventional switching power supply, the unit incorporates a toroidal transformer and advanced regulation circuits designed specifically for low noise operation. This helps provide cleaner power to the network circuitry and simplifies system integration.

What is a TCXO clock?

TCXO stands for Temperature Compensated Crystal Oscillator. This type of clock is significantly more accurate than the crystal oscillators typically found in standard networking products. Improved clock precision helps reduce timing variations and supports more accurate data transmission across the network. The Bonn N16 LPS includes a dedicated TCXO clock module for each network zone.

Can I use an external master clock with the Bonn N16 LPS?

Yes. The Bonn N16 LPS supports connection to an external 25MHz master clock. Products such as the Silent Angel Genesis GC can provide an even more precise timing reference for the switch. This allows the network infrastructure to evolve alongside the rest of a high performance digital audio system.

Is the Bonn N16 LPS compatible with Roon?

Yes. Silent Angel specifically optimized the Bonn N16 LPS for Roon based environments. It works exceptionally well with Roon Core servers, network players, music servers, and NAS devices. It is designed to support both local music libraries and streaming services within a Roon ecosystem.

How does the Bonn N16 LPS compare to the Bonn N8?

The Bonn N8 is a smaller eight port network switch designed for simpler systems. The Bonn N16 LPS adds a second isolated switch zone, doubles the port count, incorporates a built in linear power supply, provides rack mount capability, and supports larger installations. For systems with multiple networked audio devices, the N16 LPS offers substantially greater flexibility.

Is the Bonn N16 LPS difficult to install?

No. Installation is largely plug and play. Devices connect through standard Ethernet cables just as they would with any network switch. Users can configure the two zones either independently or in series depending on system requirements. No software installation or special networking knowledge is required.
